Under Slung Crane
Under-slung crane suspended directly from existing roof ceiling beams for maximum floor clearance.
1T – 10T
5 mtr - 20 mtr
Single Girder
Performance features designed for maximum safety & durability.
Standardized Construction
Versatile modular girder design adaptable to multiple industrial applications with highly reliable components.
Robot Welded Girders
Automated continuous welding ensures maximum structural strength, uniform weld seams, and ISO-certified load ratings.
Outdoor & Indoor Rated
Weather-sealed drive motors, IP55 control panels, and lattice/box girders designed to accommodate heavy industrial duties.
Complete Technical Data Sheet
All parameters can be customized according to your facility span width, lift height, and duty cycle.
Built for safe and reliable operation.
Single Girder (SG) capacity from 1 Ton to 10 Ton
Double Girder (DG) capacity from 5 Ton to 15 Ton
Span from 5 mtr to 20 mtr
Lifting height from 6 mtr to 12 mtr
Suspended from roof truss structure
No support columns required on floor
Ideal for close side-hook approach
Ideal for demanding industrial environments.
Low-ceiling buildings, cramped workshops, and restricted headroom industrial plants.
Need specialized capacity, span or lift height?
Share your site dimensions, duty cycle, and capacity requirements. Our technical sales engineers will design a customized layout for your plant.
Discuss Technical Requirement
Radio Remote Control System
Upgrade from standard push-button pendant to wireless radio remote control for enhanced operator mobility, safety, and clear load line of sight.
Get the right industrial crane solution for your facility.
Submit your technical requirements and our engineering team will provide a comprehensive commercial quote and GA drawing.
